Hi All
Thought I would recycle a thread, rather than start a new one.
I was activating Brown Clee Hill (G/WB-002) this Saturday (28/02/15) and the chasers wanted to know more about my set up.
So below are some pictures, it is a very basic setup.
The antenna is a Slim Jim, I use 450 ohm ladder feed and based the design from this page.
http://www.summits.org.uk/tiki-index.php?page=4m+J-pole
However, this link is for 300 ohm, I noticed that by adding about 30cm on the top of mine made it resonant at 70.45MHz, However David M0YDH has informed me that if you use the 300 ohm variant then the suggested dimensions are spot on.
The fishing pole is a 7m one, this photo shows the pole at about 5m - the wind prevented me from running at full height.
In terms of the rig, below is the set up
You have a Wouxun KG-699e, which is powered from a 2.2Ah LiPo, that then powers a battery eliminator (Traditionally used in cars to power up the Wouxun from the 12v supply) The LiPo performs very well and is far better than the provided 1.3Ah battery pack. Plus, it saves carrying two batteries as I normally take my 2m/70cm Wouxun as well, so all you do is swap the battery eliminator. I think at some point I will chop the cigar lighter section off and put on the standard DC connectors that I use
http://www.barenco.co.uk/radio-accessories/power-connectors/d-c-t-connector-2-pole-assembled-kit-160995
These DC connectors are cheap, if wired correctly, it is impossible to get them in the wrong
Hope that helps those that were interested, please have a go at 4m. A most rewarding band and a change from the normal 2m!
73
Matt G8XYJ
