Show us your rig! (Part 1)

Here’s my actual SOTA station.

3 Likes

Is that a Heltec module inside?

More info: Index of /~s52ft/pic/malta40

5 Likes

Hi Friends,

2014 :wink:

2016 :wink:

2018 :wink:

Actually I use HB-1B & KX2 but one more is coming :wink:

73, Jarek

8 Likes


I alternate between the FT818 and the KX1 with a 4.5 ah LiFePo and usually bring 20m and 17m hamsticks with linked ground wires.

dit dit

2 Likes

This is my portable gear for chasing Bud w8bud.

2 Likes

I mostly use the kxw with a 20 meter long HWEF. Sometimes also my QO-100 trx.

73 Chris

2 Likes

My kit built MTR2 40m/20m 5-watts with EFHW-tuner +TinySWR indicator on my “lap bench"with cup holder! (made from 1/8” plywood - weighs 3oz)

9 Likes

My kit built & repackaged MTR2 30m/20m 5-watts with IBTW paddle to EFHW-switched links for 40/30/20m on my “lap bench" with cup holder! (made from 1/8” plywood - weighs 3oz)

5 Likes

And here’s my kit-built MTR5b LCD with audio amp/speaker paddles, battery and trapped EFHE w/tuner and TinySWR indicator 10-section 17’ telescopic mast in foreground

12 Likes

My mini Sota equipment.QCX mini 20m, EndFed ant,tuner with swr indicator,paddle,paper log,Li-jon 12 v 2,3 A accumulator.

8 Likes

Hi Vasil @LZ1WF
Tks for the QSO yesterday :+1: you was strong with your QCX mini !
See you soon

73 Éric


Another toy for portable ops: Flex 1500 working with Surface Pro.

4 Likes


Tokyo Hy-Power HT-750 (7/21/50MHz 2W) at JA/YN-096 Jun


Panasonic RJX-601(50MHz AM/FM 3W born in 1973) at JA/KN-020 Jun

10 Likes

Just finished building the tr uSDX today looking forward to getting out on a summit when the knee is healed. It was powered by an emergency light that has a USB charge port 5v output to the TX and depending on the band .1 to .3w, just need to source a DC connector for it.
Managed to chase a few SOTA stations today CW on the 20/40m bands rather surprised I made the trip.



73
Graeme

10 Likes

congrats, I’m simply jealous, jealous and jealous, hi
and that just for the rig. for the unicorn: goosebump alert
73 Martin

1 Like

Hello Graeme @M0OAT.

Today I was also on the road with my truSDX near Freiburg in southern Germany.

I like the black case on yours.

All the best to you and hope you can be on the road again soon :+1:

73 Marcel DM3FAM

5 Likes

Looks like a HF-P1 in the wineyard :slight_smile:

1 Like

Hook Mountain, NY last month (W2/GC-055)

I’ve been rotating between the SW3B and MTR4BV2
using a 9v Bioenno (@3W out) and a 10/20/40 End-Fed with a simple 36’’ feedline. Remarkable QSO was with a Swedish Station.

73

Erik
KE8OKM

5 Likes

Hi
Here is my one for CW and FT8.
Toru K JA1CTV / JH0CJH

3 Likes
