Mini-charger for FT65

Equipment Radios & Power
21

I always assumed that PD negotiated the voltage and current via a protocol using a controller.

I’d be glad if this could be solved with two resistors, as you mention here. Can you give us more information?

73, Peter - HB9PJT

1 Like
22

Google Search will give you plenty to read. The Hackaday article looks good to start with. I should have a full USB spec somewhere at work. I’ll go searching and “back it up” for when I retire :wink:

EDIT: Link fixed

1 Like
23

But the device needs power to do this!

As USB C has the same connector at both ends of a cable a device cannot output power until it knows what it is connected to. The source has pull-up resistors and the sink has pull-down resistors. Different resistor values give different ratios and so the source can advertise up to 3A of 5V are available.

Anything other than 5V or beyond 15W will need some negotiation via the protocol.

2 Likes
24

Thank you for your excellent suggestions. https://hackaday.com/2023/01/04/all-about-usb-c-resistors-and-emarkers/

73, Peter - HB9PJT

3 Likes
25

I really liked the idea of this USB-C charger and after a conversation with Ian, I made a Youtube video on his charger.

In the videos description, it includes STL files and parts required. Hope it helps anyone looking to build it.

Thanks Ian for sharing!

2 Likes
26

Thanks for the great build video. Excellent improvement to the initial design too. Well done.

1 Like
