Anyone used the Radtel RT4D for DMR ?

Hello Everyone,

I have recently brought my self a Radtel RT4D DMR handheld. In someways I would say it’s better than the Baofeng UV5r that it will be replacing in my mobile setup. more audio output, better display and signal meter and has the ability to listen to Airband ( reminds me of the old AM CB radio days with all the hetertrodyning ,GREAT !). But the RX picks up much more noise and the menu system is really naff ( All my own option of course !) I have yet to get the thing working on DMR which is a mixture of not knowing if the repeaters are even there anymore, the fact the menu system seems to be different to other peoples and my complete lack of knowledge on DMR. So my question is step by step how would I program a DMR repeater in ? My Mrs is near to killing me with all the bleeping from the radio and bleeping this and bleeping that coming from me trying to get the thing working :laughing: So far I have wasted 3 evenings of my free time :laughing:

Thanks all

Brad G7SKU

1 Like

From boafengradio.com:

See if the repeater you are trying to access is on the Brandmeister network. If it is, you can go on the BM website to see if there is any activity and check if you have set it up right.

I’ve only ever accessed a local repeater with DMR and performed some functions on it (e.g. change talkgroup). Never had a contact using that mode.

1 Like

It once took me some time to get the hang of programming the codeplug for an Anytone DMR 878. I highly recommend using PC-based software for this task. Many things can only be configured on a PC.

Here is some information provided by an AI:
RT4D Codeplug Editor: A more modern tool created by developers within the community (available on GitHub) that is specifically designed to parse the .4rdmf files used by the RT-4D. It allows for more organized management of the 1024 channels, zones, and DMR contact lists via a PC.

73 Chris

1 Like

Thanks for the replies , much appreciated. Unfortunately for some reason I cannot install the software ( I have no idea why) I use Ubuntu. I have tried updating Chirp as I have read that that works better than Radtel’s own software but still cannot use it for the Radtel. Because of this I am having to program using the radio it’s self. I have listened using a none DMR radio and have a good signal on GB7WD ( part of the Salop cluster about 15 miles from me) I seem to have programmed all the correct values ( I think !) But am not getting anything back from it when I try and access the repeater. If I do get access to the repeater will I get some sort of ident or see a carrier ? My intention is to use the radio via RF to repeaters only and as I needed a replacement radio I thought I would expand my options by getting a cheap DMR replacement ( it was twice the cost of a Baofeng but was still only £44 !.

Brad G7SKU

1 Like

When you successfully reach a repeater, you won’t receive any audible feedback after releasing the PTT button. If you don’t reach it, my Anytone radio displays a warning.
You can use the BrandMeister website to look up your repeater and see if your call sign appears there.
There is also a “parrot” mode (a specific talkgroup) that plays your audio back to you. You can access this by setting up a private call to “xxx997,” where “xxx” represents the Mobile Country Code (MCC) of the master server (e.g., 262997 for Germany).
DMR is powerful, but it takes some time to learn and understand everything. Don’t give up!
73, Chris

2 Likes

Thanks for the reply Chris, So I may (or may not) be reaching the repeater without knowing it, seems a bit of a mad way of doing it ! As far as I know the the repeater is part of a closed cluster ( although I need to look into it more), the VHF and UHF bands around the centre of the UK are near dead apart from Hubnet, you can call for hours on multiple repeaters and the calling frequencies without hearing a single person ( A bit disappointing as I have no interest in HF) I was hoping that local DMR may be more active but after speaking to a local Ham on YSF ( using a phone) it seems that even digital voice is now dead, I was using a phone and he a hotspot so effectively we were playing Ham internet rather than Ham Radio ! I will keep at it and see if I hear or work anything. On the plus side I have now found the radio will TX and RX on CB radio ( I wouldn’t trust the cleanness of the TX) But I am hearing a number of stations it can also RX on AM or SSB and I am lead to believe there is an active UK legal SSB net!

1 Like

Not Radtel related but I’ve been using the Z3DMR app on my Pixel 10 Pro XL. (I have a Hytera HP605 too)

I’m in different vehicles daily and travel all over Scotland and N/England so this gives me some sort of (not real :face_savoring_food:) radio to play with on my travels. I have an Inrico B01 bluetooth mic on the way.

1 Like

I had thought about using a phone app myself in order to connect to a few repeaters on my commute as about 2/3 rds of it is in rural Shropshire ( all up and down and no good for VHF/UHF). Can you switch TX from the intrico mike ie: not touching the phone ?

1 Like

I’ve been told by the developer the PTT will work pairing the BO1 while audio should still come through vehicle.

I’ll let you know when it arrives. (currently having to tap the screen to TX driving which is safe but not ideal)

It’s a fairly new app I believe and have yet to ask about any Android Auto integration on the Telegram Group.

1 Like

In my opinion, the RT4D has rather poor programming; the CPS is not easy to use… This also applies to other Radtel DMR models, like the RT6D—I believe there are radios out there that are much simpler to program. I sold mine very quickly.

1 Like

Progress , I actually had 5 analogue contacts today which is amazing by it’s self but one of the contacts said he would try giving me a call on GB7WD when he got home ( He said it was near dead locally on DMR even worse than analogue ) I actually heard him calling me but could not get back to him :sleepy_face: I haven’t a clue what else I can do to alter anything as it all seems o.k ( colour code ,talk group , my DMR id , the slot and I’ve even monitored on a FM transceiver to make sure it is TXing on the correct frequency all these are right but it is still not working, Next plan is to try swearing at it or giving it a good kick ( joke of course, for a while at least ! ) I have just ordered a very simple Channelised Baofeng that will TX on both VHF AND UHF much like the BF888 UHF radio which may find it’s way into one of my cars ( I like simple !) and you are right the menu system is absolute pants and I look forward to hearing about the mic !

1 Like

The simple VHF/UHF radio order was cancelled by the seller :sleepy_face: I have been looking at more DMR videos and information and still have no idea why I cannot get into the repeater I even took the radio with me to work as I was going to be working in the village the repeater is in ( just in case it was poor signal causing the problem ) and it still didn’t work ! At the moment I am going to stick with analogue radios one because I’m wasting too much of my limited free time and twoI don’t think DMR is going to bring anymore contacts as everyone I speak to locally says it is totally dead anyway with most of the local infrastructure disappearing rapidly ( I think I may have come to the party too late ! ) on the plus side I found a charge cradle, belt clip and antenna for my Baofeng BF888’s at work !

1 Like

First things first. Have you registered with radioid.net to get a dmr id?

If not, you will need to dig out your license or download a pdf of your license from the ofcom website and include it as part of the account creation process.

Your dmr id will need to be put into the radio to prove you are a legitimate user.

Once you have that sorted, reply back here and we will sort you out with the next step.

1 Like

Thanks for the reply. Yes I have an id and I have entered it in the radio as Personal id.

I’m going to post my settings just in case I’m doing something obviously wrong !

Digital Settings

Personnel id =Entered

Contact list= All call

TG list =75 as per repeater

Channel settings = correct frequency and off set

DMR slot - 1 as per repeater

Colour code 11 as per repeater

Contacts all call

TG list 75 as per repeater

Channel id + made a name for it ( just numbers)

ID select = Radio ID ( bit confused by this but presume radio ID is same as Personnel id ? There is no input in the menu to change radio id !)

Radio set to DMR of course, I can hear other stations but I realised this was most likely as I had the radio set to receive in Promiscuous mode. TX and RX frequency tested with other radio

Just add to the problem the Repeater/cluster is dead and lack of repeater tail/id means I wouldn’t know if it’s working or not !

1 Like

I think you know it is working if when you press and hold PTT you get a multi tone response while holding PTT on, then you know you can go ahead and say something. if you don’t get the multi tone response you are not keying up the system. What happens in that case?

1 Like

Thanks for the reply, I get nothing at all but I have been told by a local that that is the case anyway even if it’s working ! I have taken the Radtel out of the system at the moment as it picks up my Broadband Router nearly as well as any any other signal ( and it is at risk of being lauched some where far away :grinning_face_with_smiling_eyes: ) Something I have never heard on my poor old battered Baofengs that I have returned to !

2 Likes

Looks like you’ve managed to get it working.

Instructions say use TG 75 on slot 1, or any other TG on slot 2. Not sure how that applies to ‘all call’ but maybe try slot 2 instead of slot 1.
Find out the codez to change the TG on slot 2 and see if it changes on the Brandmaster site. IIRC when running commands like that you should get a voice acknowledgement (“talkgroup changed” or similar).

Hooray ! I hadn’t a clue it was working ! I have tried it myself on the Brandmeister site just to prove it and it sees me straight away.

Thanks very much Pete

1 Like

I have now had a couple of contacts on GB7WD but unfortunately I only get a Signal reading of one fading down to zero at times and and my output is only a quarter of the repeaters output. it is causing my audio to be extremely rough and difficult to read, I have tried a different antenna and tried both antennas in different locations but this has only made it worse. The repeater is about 15 to 20 miles on high ground but I have a closer rise of land in that direction at about 1/4 of a mile so I think I’m stumped ! A homebrew beam may help but then I will have to run more coax (that I don’t have !) through the house !
