I have tried many things to keep my hands reasonably warm during CW activations.

When I first saw the crazy idea of using voice instead of a key, I couldn’t resist…

This is a very first test from home.

EDIT 2023/03/15: This is about keying a CW transmitter using voice, NOT about sending dits and dahs over SSB. Please listen carefully.

I guess the main difficulty will be to reduce the wind noise to an acceptable level so that voice can be properly detected above noise to trigger properly.

I can’t wait to try that on a summit :slight_smile:


Is that yet CW?? No, I think


Why would it be it “less” CW than when sent from a keyer or a computer keyboard ?

1 Like

This is GREAT!!!

1 Like

Absolutely it is CW because CW is a melody containing encrypted letters/cyphres.
Why not sing it.

73, Jarek

1 Like

Mike Rainey AA1TJ went one better and had the sound energy not only ‘key’ the transmitter but ‘powered’ it too!

73, Colin




Encoded not encrypted.


Sure :exclamation:
Thank you Andy :beers:

73, Jarek

1 Like

IMO: If you mean putting your rig in SSB mode, and telling dits or dahs via a mic, it is Morse code but not CW. Genuine CW is simply putting off/on a carrier to transmit the dits or dahs. The ‘mic’ mode you are describing is called MCW, very inefficient and it generates lots IMDs. It is not legal in USA for amateur radio.

See Modulated continuous wave - Wikipedia


Please listen carefully to the recording and read the link I posted in the initial post.

This is about using voice to control a CW keyer that drives a pure CW transmitter, and has nothing to do with modulated continuous wave.


That’s the first thing I checked when I read your post Christophe (voice activated CW vs. sending morse over SSB). Hams have unlimited immagination !

Kudos for trying it out; I can’t wait for an activaton (on a windless day :laughing:)


As a person almost congenitally incapable of doing Morse, I’m a little disappointed to see that this new Arduino project, good though it undoubtedly is, does not recognize human speech - e.g. “see cue SOTA dee em one see em portable”, etc. - and produce a CW signal from that. I realize I’m expecting rather too much at the moment - I don’t know if there are any speech-recognition “chips” which might be incorporated in such a thing?

Well, this would be quite a drift from the original idea.

I thought the CWvox project was crazy enough to be fun to experiment with, and incidentally, it could help keep my hands warm for some activations.

I did not use the original Arduino “sketch” but rewrote it “my way”, adding a protection to prevent the transmitter from transmitting for more than one second continuously if the noise level increases.

The Arduino part is definitely not needed. However, it makes it very easy to play with the software to experiment with various timings, trigger values, etc.

Should I decide after experimenting from summits that I want to keep using this idea, I would probably replace the Arduino by a couple of 555’s and make the whole circuit small and light enough to fit in a proper SOTA CW go-kit.

Now for the speech-to-morse wish, there are plenty of speech recognition tools that can generate text (like subtitles) from speech, and also lots of programs that convert text to morse code. So it would definitely be technically feasible, but probably less reliable than using a keyboard to generate the morse code directly.

For Arduino, there is for example the Arduino Speech Recognition Engine ( Arduino Speech Recognition Engine — Arduino Official Store ).

It would definitely be fun to develop. Would it still be fun to use though ?

1 Like

Probably not, given all the other hindrances and obstacles present in the average SOTA activation. But maybe in 10 (?) years from now, when the newest AI of the time could be squeezed onto a chip (Moore’s law) it might be feasible. But probably still not so much fun as interacting with other stations by voice, with all its’ attendant “features.”

@DM1CM Your wish is granted:


Well, blow me down, as Popeye would say!
